Non-Retractable Fixed-Point Shoulder Belt with Quick Disconnect
Sure-Lok FE200865 Non-Retractable Quick Disconnect Shoulder Belt (63″ length) mounts to OEM shoulder belt anchors and features single push-button release for dual-use flip seat/wheelchair configurations.
Includes: Qty 1 Non-Retractable Fixed-Point Shoulder Belt w/Quick Disconnect | FE200865
KEY FEATURES:
- OEM Anchor Compatible: Shares existing vehicle shoulder belt mounting point.
- Quick Disconnect Buckle: Single push-button release for flip seat conversion.
- Dual-Use Design: Wheelchair securement or ambulatory passenger use.
- 63″ Fixed Length: Optimized for standard wheelchair bay geometry.
- Pigtail Anchor Strap: Connects to wheelchair frame during securement.
This 63″ fixed-length shoulder belt attaches to existing vehicle OEM shoulder belt anchor bolts alongside factory belts. Quick disconnect buckle allows easy removal for flip seat passengers (using OEM belt) or connection to wheelchair short anchor strap during securement. Essential for multi-position wheelchair bay occupant protection.
Dual-Use Operation:
| Mode | Configuration |
|---|---|
| Flip Seat Passenger | Disconnect → Remove → OEM belt only |
| Wheelchair Occupant | Connect → Buckle to wheelchair pigtail → Complete restraint |
OEM Shoulder Anchor ── Factory Belt ──┐
└─ FE200865 (63") ── Quick Disconnect ── Wheelchair Pigtail
Standards Compliance:
| Standard | Test Criteria |
|---|---|
| SAE J2249 | 30mph/20g impact |
| CSA Z605 | 30mph/20g Canadian |
| FMVSS 222 | School bus protection |
| ADA 49 CFR Part 38 | Accessibility |
| FMVSS 209/210/302 | Seat belts/flammability |
WARNING: Requires lap belt pairing. Not standalone wheelchair securement.
Applications:
- Flip seat/wheelchair bay dual configurations
- School buses with convertible seating
- Paratransit vans with multi-position bays
- OEM belt integration required vehicles
Required Components:
| Component | Purpose |
|---|---|
| Lap Belt | FE200637-14 (wheelchair occupant lower torso) |
| Wheelchair Securement | FF600/AL700 kits (4-point tie-downs) |
| Pigtail Anchor | Included wheelchair frame attachment |
